NMD MEZ EXPERIMENTAL - ARCFLEX WIFLY BAT
EXP SERIES V2 — ARCFLEX WIFLY BAT
The second release from my Experimental Series.
A design collaboration with Kieran Adshead.
ArcFlex™ is the fifth evolution of our flagship PFS core technology. Twin recurve Divinycell™ beams create a pre-loaded flex pattern that stores and rapidly releases energy for explosive recoil, greater projection, and a fast, responsive ride.
The WiFly™ Bat Tail combines the lift and speed of a bat tail with the hold and control of a performance crescent. Working in harmony with ArcFlex™, it delivers effortless speed, powerful drive, and precise control across a wide range of conditions.
The second release from my Experimental Series.
A design collaboration with Kieran Adshead.
ArcFlex™ is the 5th evolution of our flagship PFS core construction. Twin recurve Divinycell™ beams are engineered to create a pre-loaded flex pattern within the core. As the board is compressed under load, the curved beam architecture stores energy through controlled inward flex. When pressure is released, that stored energy is rapidly transferred back through the board, generating powerful recoil, increased projection, and a fast, reactive feel.
The WiFly™ Bat Tail is engineered to unlock that energy. Combining the lift and acceleration of a bat tail with the hold and control of a performance crescent, its wider planing platform maintains speed through flatter sections while amplifying the recoil characteristics of ArcFlex™. The result is effortless speed, enhanced projection, and a fast, controlled ride in a wide range of conditions.
Designed for riders seeking maximum drive, projection, and responsiveness, the EXP V2 pushes the boundaries of conventional bodyboard design
BOARD TECH
Core - 1.9lb PP Polypropylene - ArcFlex PFS Core Integration
Stringer - 1x CFT Stringer
Rails - 55/45 Rails
Channels - Aku Parallel Channels
Slick - Dupont Surlyn Slick Skin
Deck - Wavecushion Air 8lb PE Deck with Q12 Backing Foam
Tail - Wifly Bat Tail
Additional Features - Traxion Contour, MESH, CNC Shaped, XFL Inner Rails, Bull Grip Nose Bulbs, Nose & Tail Guards.
BOARD TECHNOLOGY INDEX
Kinetic PP - Constructed from premium grade 1.9lb density Polypropylene Kinetic Core delivers amazing projection and response as high pressure cell-fusion created during the blanks manufacturing process.Kinetic Core is a warm water core available in various reinforcements configurations, each tuned-in for specific wave conditions.
CFT Stringer - High grade lightweight filament wound composite fibre tube for increased board strength and spring like recoil.
React Mesh - Diamond shaped mesh weave fused between the boards core and slick bottom skin for the enhanced stiffness and recoil
Surlyn Slick - Dupont Surlyn Slick is the finest grade bottom skin for a bodyboard because of its rubber like properties, superior recoil and resistance to scratching and wear and tear , hence the reason why Surlyn is the universal skin used for Golf Balls.
Wavecushion 8lb NXLPE - 8pcf non-crosslink Polyethylene outer skins. The premier skin for high performance bodyboarding.
Q12 - Higher density crosslinked PP Foam backing layer delivers more resilient nose and tail seam fusion and increase board strength.
DECK CONTOURS Dual purpose deck contouring specifically designed to create dedicated flex zones for torsional and nose-to-tail response, integrated with functional handgrip placement.
XFL Armour - Heat laminated Crosslink foam forms the inner rails and nose tail armour encapsulating the full inner perimeter of the board for premium seam strength and impact protection.
CNC Precision Shaping - CAD designed templates precision cut with CNC shaping machines for superior accuracy and consistency.
Bull Grips - Die-cut foam bulbs are positioned at each corner of the nose to enhanced finger grip and with a curved contour for an even better handle.
Buzz Tech Lamination - Buzz Tech process hot air lamination system Thermo-fuses the outer skins to the core with calibrated pre and post set rocker tension for optimum board recoil and projection.
